Equipping the RED KOMODO-X with the LeftField System

komodo x compatibility 01

RED has just announced the KOMODO-X camera, which is positioned between the KOMODO® and V-RAPTOR models. Here’s everything you need to know about using the RED KOMODO-X camera with your existing or new LeftField System.

B4002 0222 LF3 Expert Kit KOMODO X 00 web
LeftField 3 Expert Kit for the RED KOMODO-X/product-category/red-komodo-x/

What are the key differences between the KOMODO & KOMODO-X?

Size comparison of RED KOMODO & KOMODO-X. Image from RED.com
Size comparison of RED KOMODO & KOMODO-X. Image from RED.com

The KOMODO-X looks similar to the original KOMODO but features an elongated body, native micro v-lock mount, additional IO, and is compatible with the RED DSMC3 Touch 7″.

Highlighting the different screw spacing of the KOMODO (12.5mm) & KOMODO-X (25mm)
Highlighting the different screw spacing of the KOMODO (12.5mm) & KOMODO-X (25mm)

The main difference in compatibility and fit with current accessories is the repositioned mounting point on the bottom of the camera, while the original KOMODO has a screw spacing of 12.5mm, the KOMODO-X has a spacing of 25mm.

Additionally, the KOMODO-X features a locking RF mount and a run/stop button on the front of the camera. These two differences are the main factors that will impact compatibility with our current product offering.

Is the LeftField KOMODO System compatible with the KOMODO-X?

LeftField accessories with the RED KOMODO-X. Photo courtesy of Peter Choi - Lost Kuma
LeftField accessories with the RED KOMODO-X. Photo courtesy of Peter Choi – Lost Kuma

For the most part, the LeftField KOMODO System is compatible with the KOMODO-X. However, the RED KOMODO dovetails (B4002.1030 & B4002.1031) and the lens support adapters (B4002.1019, B4002.1020, B4002.1021 & B4002.1026) that attach to the side and top plates are not compatible.

How can I make my existing kit compatible with the KOMODO-X?

I have the standard riser

B4002 1023 Standard Riser for 15mm Baseplate KOMODO web
B4002 1023 Standard Riser for 15mm Baseplate KOMODO web

If you own a LeftField 15mm LWS Baseplate with the standard riser (B4002.1023) you will need to contact our customer support team to special order the washer plate for the KOMODO-X. The washer plate provides the correct screw spacing and proper fitment of the camera to the baseplate.

The updated Standard Riser for KOMODO & KOMODO-X (B4002.1123) will include washer plates for both the KOMODO & KOMODO-X.

I have the DJI riser

B4002 1018 RED Komodo DJI Riser 02 web
B4002.1018 DJI RS 2 & 3 Riser for the RED KOMODO

To use the DJI riser with the KOMODO-X, you will require a new dovetail that can accommodate the screw spacing of KOMODO-X.

B4002.1030 & B4003.1031 DJI Dovetails are only compatible with the RED KOMODO. Not the KOMODO-X.
B4002.1030 & B4003.1031 DJI Dovetails are only compatible with the RED KOMODO. Not the KOMODO-X.

To use the KOMODO-X with the DJI Riser, you will need to use B4002.1071 Universal Extended DJI RS 2 & RS 3 Dovetail. Our universal dovetails feature shuttles with adjustable screw spacing to work with multiple cameras.

Both dovetails will maintain the correct 15mm LWS height when combined with the DJI RS 2 & RS 3 Riser (B4002.1018)

DJI RS 2 & RS 3 Compatible Dovetail

Other Compatible Accessories for the RED KOMODO-X

RED DSMC3 7" Touch mounted on the monitor mount (B4002.1068) shown on the V-RAPTOR
RED DSMC3 7″ Touch mounted on the monitor mount (B4002.1068) shown on the V-RAPTOR

The RED KOMODO-X now has support for the RED DSMC3 TOUCH 7″ Monitor using the Pogo pins. To relocate the monitor, you can use the Monitor Mount for DSMC3 RED Touch (B4002.1068).

Is the RED Outrigger Handle still compatible?

RED Outrigger handle mounted on the Run/Stop Top Rail
RED Outrigger handle mounted on the Run/Stop Top Rail

Yes, you can use the RED Outrigger handle with the RED KOMODO-X as well as in combination with our Run/Stop NATO Top Rail (B4002.1027).

Fitting out a RED KOMODO-X Cage

RED KOMODO with the KASBAH hand grips & Misfit Kick matte box
RED KOMODO with the KASBAH hand grips & Misfit Kick matte box

If you’re in the market for a brand-new KOMODO-X and want to kit it out from scratch, we have some fantastic kit offerings that will make the process a lot easier.

You can choose from a range of accessories such as the KASBAH support system, matte boxes, brackets, and much more, all of which are compatible with the KOMODO-X. With our kit offerings, you can take your KOMODO-X to the next level and unlock its full potential.

Compatibility Table

Here is a comprehensive list of accessories and their compatibility with the RED KOMODO, KOMODO-X, V-RAPTOR, and V-RAPTOR XL.

SKU Name KOMODO-X KOMODO V-Raptor V-Raptor XL
B4002.1007 Top Rail for RED KOMODO & KOMODO-X x x x x
B4002.1008 Left Side Rail for RED KOMODO & KOMODO-X x x
B4002.1009 Right Side Rail for RED KOMODO & KOMODO-X x x
B4002.1018 DJI RS 2 & 3 Riser for 15mm Baseplate (RED KOMODO & KOMODO-X) x x
B4002.1019 Vocas RF-PL Support for RED KOMODO x
B4002.1020 KipperTie Revolva/Adapta RF Support for RED KOMODO x
B4002.1021 Metabones RF-PL Support for RED KOMODO x
B4002.1023 Standard Riser for 15mm Baseplate for RED KOMODO x
B4002.1123 Standard Riser for 15mm Baseplate (RED KOMODO & KOMODO-X) x x
B4002.1025 Cheeseplate for RED KOMODO & KOMODO-X x x
B4002.1026 Canon 0.71x Expander Support for RED KOMODO x
B4002.1027 Run/Stop NATO Top Rail for DSMC3 x x x x
B4002.1030 DJI RS 2 & RS 3 Dovetail for RED KOMODO x
B4002.1031 DJI RS 2 & RS 3 Extended Dovetail for RED KOMODO x
B4002.1050 Right Side Plate for RED V-RAPTOR x
B4002.1051 Right Side Horse Shoe for RED V-RAPTOR x
B4002.1052 Top Handle for DSMC3 x x x x
B4002.1053 Sliding Top Plate for RED V-RAPTOR x
B4002.1054 Left Side Plate for RED V-RAPTOR x
B4002.1058 Universal Extended DJI Ronin 2 Dovetail x x x x
B4002.1059 Universal Extended Manfrotto Dovetail x x x x
B4002.1061 Universal Extended Movi Pro Camera Plate x x x x
B4002.1062 RED V-RAPTOR (Manfrotto/DJI RS) Riser for 15mm Baseplate x
B4002.1063 RED V-RAPTOR (DJI Ronin 2) Riser for 15mm Baseplate x
B4002.1065 RED V-RAPTOR (Movi Pro) Riser for 15mm Baseplate x
B4002.1066 Top Bar Bracket for DSMC3 x x x x
B4002.1068 Monitor Mount for DSMC3 RED Touch 7″ x x x x
B4002.1069 Standard Riser for RED V-RAPTOR x
B4002.1070 Top Plate QR Dovetail x
B4002.1071 Universal Extended DJI RS 2 & RS 3 Dovetail x x x x
B4002.0015 Side Plate Kit for RED KOMODO & KOMODO-X x x
B4002.0009 Essentials Kit for RED KOMODO & KOMODO-X x x
B4002.0018 15mm Top Plate Kit for RED KOMODO & KOMODO-X x x x x
B4002.0017 Top Plate Kit for RED KOMODO & KOMODO-X x x x x
B4002.0110 LeftField 3 Base Kit for RED KOMODO x
B4002.0122 LeftField 3 Expert Kit for RED KOMODO (DJI RS 2 & RS 3) x
B4002.0123 LeftField 3 Advanced Kit for RED KOMODO (DJI RS 2 & RS 3) x
B4002.0210 LeftField 3 Base Kit for RED KOMODO & KOMODO-X x x
B4002.0223 LeftField 3 Advanced Kit for RED KOMODO & KOMODO-X (DJI RS 2 & RS 3) x x
B4002.0222 LeftField 3 Expert Kit for RED KOMODO & KOMODO-X (DJI RS 2 & RS 3) x x
B4002.0020 Riser Kit for 15mm Baseplate for RED KOMODO (DJI RS 2 & RS 3) x
B4002.0113 LeftField 3 QR Baseplate (Standard) for RED KOMODO x
B4002.0121 LeftField 3 QR Baseplate for RED KOMODO (DJI RS 2 & RS 3) x
B4002.0213 LeftField 3 QR Baseplate (Standard) for RED KOMODO & KOMODO-X x x
B4002.0221 LeftField 3 QR Baseplate for RED KOMODO & KOMODO-X (DJI RS 2 & RS 3) x x
